FRESH REED PETALS EQUALS MAXIMUM PERFORMANCE
Designed for 2000 ski doo Summit 600, these Boyesen reeds help improve intake response, airflow efficiency, and throttle control for a stronger, more responsive ride.
Maximum Power is acheived by keeping your Boyesen Rage Cage equipped with fresh reed petals. Boyesen Rage Cage Replacement Reed Petals are one of the critical aspects of why the Rage Cage works so well. In order to keep your Boyesen Rage Cage performing at peak capacity you will need to change the reed petals at least 2 times per season depending on how much and how hard you ride. Boyesen Rage Cage Replacement Reed Petals feature a carbon-fiber top petal that has excellent response characteristics providing improved acceleration and stronger throttle response and are designed to operate specifically with the Rage Cage Reed air intake system. Boyesen engineers craft and hand tension every Rage Cage Replacement Reed Petal set to work optimally with each respective parent Rage Cage Reed assembly to create the performance advantage that the Rage Cage is known to produce.
Keep your Rage Cage optimized by inspecting and changing it’s reed petals frequently. The result… superior efficiency, peak horsepower gains, and acceleration for YOUR specific model machine. Each Boyesen Rage Cage is unique - tailor made to that model, year and displacement. Please double check our cross reference information to ensure that you order the correct Rage Cage Replacement Reed Petals for the proper Rage Cage in your machine.


MS PLUS FLOW OPTIMIZATION
The patented multi-stage design incorporates a specially shaped top reed petal and a ported bottom reed petal. The top petal is lightweight and resilient for crisp throttle response at partial throttle or low RPM. The stiffer, bottom petal is ported to provide maximum flow and horsepower at higher RPM. By using a multiple reed petal stack, it is possible to acheive peak horsepower, more torque, improved stall resistance and greater overall reed durability.
FREE REVING POWER
The dual-stage design allows you to replace your stock reed stop with a Rev-Plate which permits the reeds to open freely and function efficiently. This results in a free reving, yet extremely smooth power delivery with an improved connection between your hand, the rear wheel and the terrain.part number cross reference
| boyesen part number | serial number (start) | serial number (end) | UPC number | eu hts number | Southern number |
|---|---|---|---|---|---|
| PRO-137 | 804429007783 | 84099100900 | |||
| parts unlimited | parts europe | tucker rocky | wpc | apico int | |
| 59-1522P2 | |||||
| bihr | dist 1 | dist 2 | dist 3 | dist 4 | |
Applications
| Machine type | make | model | year range | cc | FUEL SYSTEM | CYLINDERS |
|---|---|---|---|---|---|---|
| SNOWMOBILE | polaris | 500 Classic | 2003-2003 | 500 | ||
| SNOWMOBILE | polaris | 500 Edge | 2003-2004 | 500 | ||
| SNOWMOBILE | polaris | 500 Indy | 1999-2002 | 500 | ||
| SNOWMOBILE | polaris | 500 RMK | 1997-2002 | 500 | ||
| SNOWMOBILE | polaris | 500 SKS Euro | 2000-2002 | 500 | ||
| SNOWMOBILE | polaris | 500 XC | 1999-2003 | 500 | ||
| SNOWMOBILE | polaris | 500 XC SP | 1999-2007 | 500 | ||
| SNOWMOBILE | polaris | 600 Classic | 2001-2006 | 600 | ||
| SNOWMOBILE | polaris | 600 Edge Touring | 2005-2006 | 500 | ||
| SNOWMOBILE | polaris | 600 Pro X | 2001-2004 | 600 | ||
| SNOWMOBILE | polaris | 600 RMK | 1998-2005 | 600 | ||
| SNOWMOBILE | polaris | 600 Switchback | 2004-2005 | 600 | ||
| SNOWMOBILE | polaris | 600 Touring | 2000-2000 | 600 | ||
| SNOWMOBILE | polaris | 600 XC SP | 1996-2004 | 600 | ||
| SNOWMOBILE | polaris | 600 XCR | 1996-1998 | 600 | ||
| SNOWMOBILE | polaris | 600 XCR | 1996-1998 | 600 | ||
| SNOWMOBILE | polaris | 700 Classic | 2001-2004 | 500 | ||
| SNOWMOBILE | polaris | 700 Edge RMK | 2003-2003 | 700 | ||
| SNOWMOBILE | polaris | 700 EV XC SP Edge | 2001-2001 | 700 | ||
| SNOWMOBILE | polaris | 700 Pro X | 2003-2004 | 700 | ||
| SNOWMOBILE | polaris | 700 RMK | 1997-2005 | 700 | ||
| SNOWMOBILE | polaris | 700 SKS | 1997-2003 | 700 | ||
| SNOWMOBILE | polaris | 700 Switchback | 2004-2004 | 700 | ||
| SNOWMOBILE | polaris | 700 XC | 1997-2005 | 700 | ||
| SNOWMOBILE | polaris | 700 XCR | 1998-1999 | 700 | ||
| SNOWMOBILE | polaris | 700 XCR | 1998-1999 | 700 | ||
| SNOWMOBILE | polaris | 800 Classic | 2003-2004 | 800 | ||
| SNOWMOBILE | polaris | 800 Edge Touring | 2005-2005 | 800 | ||
| SNOWMOBILE | polaris | 800 LE | 2001-2001 | 800 | ||
| SNOWMOBILE | polaris | 800 Pro X | 2003-2004 | 800 | ||
| SNOWMOBILE | polaris | 800 Pro XR | 2004-2004 | 800 | ||
| SNOWMOBILE | polaris | 800 RMK | 2000-2005 | 800 | ||
| SNOWMOBILE | polaris | 800 SKS | 2003-2003 | 800 | ||
| SNOWMOBILE | polaris | 800 Switchback | 2004-2005 | 800 | ||
| SNOWMOBILE | polaris | 800 XC | 2001-2005 | 800 | ||
| SNOWMOBILE | ski doo | Formula 600 | 2000-2001 | 600 | ||
| SNOWMOBILE | ski doo | Formula Deluxe 500 | 2001-2001 | 500 | ||
| SNOWMOBILE | ski doo | Formula III (3-cylinder) | 1996-1998 | 600 | ||
| SNOWMOBILE | ski doo | Formula III 700 (3-cylinder) | 1998-2000 | 700 | ||
| SNOWMOBILE | ski doo | Formula III 800 (3-cylinder) | 1999-2000 | 800 | ||
| SNOWMOBILE | ski doo | Grand Touring 500 | 2001-2003 | 440 | ||
| SNOWMOBILE | ski doo | Grand Touring 600 | 2000-2003 | 600 | ||
| SNOWMOBILE | ski doo | Grand Touring 700 (3-cylinder) | 1998-2003 | 700 | ||
| SNOWMOBILE | ski doo | Grand Touring 800 (3-cylinder) | 2001-2002 | 800 | ||
| SNOWMOBILE | ski doo | GSX 500SS | 2004-2007 | 600 | ||
| SNOWMOBILE | ski doo | GTX 500SS | 2005-2006 | 600 | ||
| SNOWMOBILE | ski doo | GTX Sport 500SS | 2007-2008 | 600 | ||
| SNOWMOBILE | ski doo | Legend 500 | 2002-2003 | 500 | ||
| SNOWMOBILE | ski doo | Legend 500SS | 2004-2004 | 600 | ||
| SNOWMOBILE | ski doo | Legend 600 | 2002-2003 | 600 | ||
| SNOWMOBILE | ski doo | Mach 1 (3-cylinder) | 1997-2000 | 800 | ||
| SNOWMOBILE | ski doo | Mach 1 (693 RV) (3-cylinder) | 1996-1996 | 780 | ||
| SNOWMOBILE | ski doo | Mach Z (3-cylinder) | 1997-2003 | 800 | ||
| SNOWMOBILE | ski doo | Mach Z LT | 1997-1999 | 800 | ||
| SNOWMOBILE | ski doo | Mach Z LT | 1996-1996 | 780 | ||
| SNOWMOBILE | ski doo | MXZ 440 | 1999-2002 | 440 | ||
| SNOWMOBILE | ski doo | MXZ 500 | 2000-2003 | 440 | ||
| SNOWMOBILE | ski doo | MXZ 500 | 2000-2003 | 440 | ||
| SNOWMOBILE | ski doo | MXZ 500 SS | 2004-2007 | 600 | ||
| SNOWMOBILE | ski doo | MXZ 500SS | 2007-2007 | 600 | ||
| SNOWMOBILE | ski doo | MXZ 600 | 1999-2003 | 600 | ||
| SNOWMOBILE | ski doo | Skandic 600 | 2001-2003 | 600 | ||
| SNOWMOBILE | ski doo | Skandic SUV 600 | 2003-2007 | 600 | ||
| SNOWMOBILE | ski doo | Skandic SUV 600 | 2009-2009 | 600 | ||
| SNOWMOBILE | ski doo | Skandic WT 600 | 2004-2010 | 600 | ||
| SNOWMOBILE | ski doo | Summit 600 | 1999-2002 | 600 |
extended fitment
Polaris 800 RMK 00-05, Polaris 800 Pro X 03-04, Polaris 800 Classic 03-04, Polaris 700 XCR 98-99, Polaris 700 XC 97-05, Polaris 700 Switchback 04, Polaris 700 SKS 97-03, Polaris 700 RMK 97-05, Polaris 700 Pro X 03-04, Polaris 700 EV XC SP Edge 01, Polaris 700 Edge RMK 03, Polaris 700 Classic 01-04, Polaris 600 XCR 96-98, Polaris 600 XC SP 96-04, Polaris 600 Touring 00, Polaris 600 Switchback 04-05, Polaris 600 RMK 98-05, Polaris 600 Pro X 01-04, Polaris 600 Edge Touring 05-06, Polaris 600 Classic 01-06, Polaris 500 XC SP 99-07, Polaris 500 XC 99-03, Polaris 500 SKS Euro 00-02, Polaris 500 RMK 97-02, Polaris 500 Indy 99-02, Polaris 500 Edge 03-04, Polaris 500 Classic 03, Polaris 800 Pro XR 04, Ski Doo MXZ 500 00-03, Polaris 800 Edge Touring 05, Polaris 800 LE 01, Polaris 800 XC 01-05, Polaris 800 Switchback 04-05, Polaris 800 SKS 03, SKI DOO Formula Deluxe 500 01, SKI DOO Formula 600 00-01, SKI DOO Grand Touring 500 01-03, SKI DOO Grand Touring 600 00-03, SKI DOO Legend 500 02-03, SKI DOO Legend 600 02-03, SKI DOO MXZ 440 99-02, SKI DOO MXZ 600 99-03, SKI DOO Skandic 600 01-03, SKI DOO Skandic SUV 600 03-07, SKI DOO Skandic SUV 600 09, SKI DOO Skandic WT 600 04-10, SKI DOO Summit 600 99-02, SKI DOO Formula III 96-98, SKI DOO Formula III 700 98-00, SKI DOO Formula III 800 99-00, SKI DOO Grand Touring 700 98-03, SKI DOO Grand Touring 800 01-02, SKI DOO Mach 1 97-00, SKI DOO Mach 1 (693 RV) 96, SKI DOO Mach Z 97-03, SKI DOO Mach Z LT 97-99, SKI DOO Mach Z LT 96, SKI DOO GSX 500SS 04-07, SKI DOO GTX 500SS 05-06, SKI DOO GTX Sport 500SS 07-08, SKI DOO Legend 500SS 04, SKI DOO MXZ 500 SS 04-07, SKI DOO MXZ 500SS 07
